Drawing ballooning and first article inspection

Drawing Ballooning and Guided Shop Floor Inspection

Quality teams prepare PDF drawings, review extracted dimensions, and record shop-floor measurements in one browser workflow. Enterprise licensing adds on-prem and air-gapped deployment when controlled drawings must stay in your network.

Review the drawing. Capture the measurement. Prepare the report.

Seat plans include a 14-day trial and do not require a credit card. Enterprise licensing is arranged with sales.

Actual inspection application showing a ballooned synthetic PDF, eight measured characteristics, seven OK results and one NOK result.
Actual application screenshot · synthetic test drawing and example measurements. The 25.20 mm result exceeds the 25.10 mm upper limit, so the inspection is marked rejected.

Deployment

Deployment options for controlled drawings

Where QuickFAI runs, and how site and multi-site licenses are structured for quality and manufacturing teams.

  • On-prem and air-gapped

    Enterprise Mid and Large can run inside your perimeter, including air-gapped deployment with Docker. Seat plans stay hosted.

  • AS9102 form support

    Enterprise plans produce AS9102 Forms 1, 2, and 3 from ballooned drawings, with CMM import on Enterprise Mid and above. QuickFAI supports the package. Your team still approves it.

  • Drawings stay in your network

    On-prem and air-gapped deployments keep controlled drawings on your network. Confirm the deployment before uploading controlled data to a hosted plan.

  • Browser and shop-floor tablets

    Inspectors review drawings and record measurements in a web browser on a desktop or tablet. Shop Floor Pro adds full-screen guided inspection and keyboard-wedge gauge input.

  • Enterprise licensing

    Single-site licensing from $2,000 per month. Multi-site and OEM licensing from $5,000 per month. Seat plans start at $39 per user per month.

Workflow

The Seamless Quality Workflow

Connect drawing preparation, measurement entry, and inspection report preparation in the browser.

  1. Step 1 / 3

    Auto-Balloon in One Click

    Prepare dimensions and tolerances from 2D PDFs with OCR-assisted extraction. Review symbols, values, and drawing context before releasing the plan.

  2. Step 2 / 3

    Guided Data Entry

    Go full-screen. The app auto-focuses on each balloon sequentially. Enter values manually or connect your digital calipers via keyboard wedge input.

  3. Step 3 / 3

    Instant Reports & Defect Logging

    Prepare inspection reports from recorded results. Review out-of-tolerance measurements and document discrepancies under your quality procedure.

Explore the workflow

One drawing. A clear path to the inspection record.

See how numbered requirements connect drawing review with measurement entry. The example below uses a fictional part.

Pricing

Transparent, Predictable Pricing

Seat plans for inspection stations. Site and multi-site licenses when the software has to run in your environment.

Starter Plan

Ballooning and reporting for standalone quality techs getting off paper.

$39/ user / month

Billed monthly · or $390 / year

  • Auto-ballooning 2D PDF engine
  • Intelligent OCR dimension extraction
  • Standard Excel/PDF report export
  • 14-day free trial
Choose Starter
Guided inspection

Shop Floor Pro

Guided, caliper-connected inspection right at the machine.

$79/ user / month

Billed monthly · or $790 / year

  • Everything in Starter Plan
  • Full-screen guided inspection mode
  • Keyboard wedge caliper input
  • Non-Conformance logging & export
  • Priority email support
Get Started with Pro
On-Prem · Air-Gapped

Enterprise Mid

For single-site manufacturers and aerospace suppliers who need FAI on their own servers.

From$2,000/ month

Billed as a flat corporate fee

  • Site licenseUnlimited users at one manufacturing site.
  • On-Premise or 100% Air-Gapped deploymentRuns inside your perimeter via Docker containers.
  • CMM data import & AS9102 FAI formsForms 1, 2 and 3 generated straight from ballooned drawings.
  • Drawings stay in-houseZero data leaves your network.
  • Support arranged with salesA custom SLA is available on request.
Contact sales
Whitelabel · OEM

Enterprise / OEM Large

For software vendors and multi-site manufacturing groups that need whitelabel rights, private deployment, and a defined support arrangement.

From$5,000/ month

Billed as a flat corporate fee

  • Everything in Enterprise Mid
  • Full Whitelabel & OEM RightsFully re-brand the entire engine under your own name and logo.
  • Multi-site deploymentDedicated private cloud or on-premise across all your plants.
  • No per-seat capShop floor users, drawings, and automated OCR extractions.
  • Direct MES / ERP API integration modules
  • Deployment support, customer-administered usersQuickFAI maintains the deployed software. Your team administers end users. Support terms, including a custom SLA, are agreed with sales.
Contact sales

IP & Drawing Security: Dedicated cloud isolation and enterprise-grade encryption are standard for all Enterprise tiers. Custom SLA available upon request.

Frequently Asked Questions

Is QuickFAI a web-based FAI report tool?

Inspectors use QuickFAI in a web browser on a desktop or shop-floor tablet. Hosted seat plans do not require a desktop install. Enterprise plans can also be deployed on-prem or air-gapped when drawings cannot leave your network.

How is enterprise licensing structured?

Enterprise Mid is a single-site license from $2,000 per month, with on-prem and air-gapped deployment. Enterprise / OEM Large starts at $5,000 per month and adds multi-site deployment, whitelabel rights, and API integration modules. Seat plans remain available for individual inspection stations.

Does this work as an alternative to desktop ballooning software?

QuickFAI is a browser-based workflow for PDF drawing ballooning and inspection report preparation. Compare supported inputs, report outputs, and deployment options, including on-prem, with the desktop process your quality team uses today.

How does digital caliper input work?

The guided inspection interface supports standard keyboard-wedge input. When an inspector presses the data-send button on a compatible Bluetooth or USB caliper, the measurement is written into the active balloon and the workflow moves to the next characteristic. Confirm the gauge, units, and connection before a production inspection.

Which plans include AS9102 forms?

Enterprise Mid and Enterprise / OEM Large include AS9102 Forms 1, 2, and 3 generated from ballooned drawings, plus CMM data import. Standard Excel and PDF inspection exports are on the seat plans. QuickFAI supports preparation of the package. It does not replace your review and approval against the applicable standard and customer requirements.

What support is included?

Shop Floor Pro includes priority email support. Enterprise support terms are agreed with sales, and a custom SLA is available on request. QuickFAI maintains the deployed software. Your quality and IT teams administer users and the inspection process.
